ClaveMed 3L Autoclave

The ClaveMed Autoclave: Pre-programmed Cycles to Suit All Your Needs

7 Sterilization Cycles + Automatic Cleaning Cycle:

Program	Temperature/Pressure	Sterilization Time	Total Duration
Quick S	134 °C / 210 kPa	3.5 minutes	7–11 minutes
Standard B	134 °C / 210 kPa	4 minutes	15–18 minutes
Soft B	121 °C / 110 kPa	20 minutes	25–30 minutes
Prion 134	134 °C / 210 kPa	18 minutes	25–30 minutes
Test B&D	134 °C / 210 kPa	3.5 minutes	12–18 minutes
Test Helix	134 °C / 210 kPa	3.5 minutes	12–18 minutes
Vacuum Test	–	–	15–20 minutes

The sterilization and drying time is adjustable according to the load and preheating.

The ClaveMed Autoclave: Advanced Features for Professional Use

• Integrated Steam Generator (2000 W)

Allows for rapid temperature rise and shorter sterilization cycle.

• Manual Door System with Enhanced Safety

• Automatic secure locking

• Warning for improper closure

• Overpressure valve

• Anti-overheating safety switch

• Smart Memory and Connectivity

• USB Port: automatic backup of each cycle (up to 9999)

• Printer Port: for printing sterilization reports

• Barcode Label Port: for perfect traceability of each instrument

• Easy Maintenance

• Integrated descaling cycle to automatically clean the steam generator and internal conduits

• Automatic maintenance warning

Focus on the Strengths of the ClaveMed F: Technology, Safety, and Performance

The ClaveMed F is designed to meet the strictest sterilization requirements in professional environments. Thanks to its intelligent design and high-quality components, it ensures speed, safety, and reliability in every cycle.

Maximum Protection at All Levels

The ClaveMed F is equipped with multiple mechanical and electronic safety devices to ensure risk-free use:

• Protection against overheating

• Protection against overpressure

• Secure locking of the door • Alert system in case of malfunction or handling error Result: total peace of mind during each sterilization cycle.

Simple data export

This model is standardly equipped with internal memory capable of storing more than 9999 cycles. Each cycle is recorded and can be automatically saved via a USB key. This function facilitates the traceability of procedures and compliance with current health requirements.

Reliability and European compliance

The ClaveMed F is fully compliant with current European standards for class B steam sterilizers. The manufacturing quality is certified, ensuring: • Complete and secure sterilization • Stable long-term performance • Optimal safety level for you and your patients

Suitable for all types of loads

The ClaveMed F is a class B autoclave, meaning it can be used to sterilize all types of loads, including: • Hollow instruments • Porous materials • Solid instruments, packaged or not It is therefore perfectly suited for medical, podiatry, aesthetic, or dental practices, where a variety of instruments is common.

Integrated intelligent descaling cycle

The ClaveMed F includes an intelligent descaling cycle that automatically cleans the device's internal conduits using descaling powder or liquid. This function extends the autoclave's lifespan while ensuring optimal sterilization, cycle after cycle.

In summary – What the ClaveMed F offers you:

Feature	Advantage
Super Fast	Ultra-fast cycles thanks to instant steam
Multi Protection	Complete safety: overpressure, overheating, locking
Data Export	Storage of over 10,000 cycles, easy export via USB
Reliability	Full compliance with CE and international standards
Versatility	Suitable for all types of instruments (hollow, solid, porous)
Intelligent descaling	Automatic cleaning of conduits with descaling solution

An appliance compliant with European and international standards

The ClaveMed F meets the strictest safety and quality standards in force: • Directive 93/42/EEC (medical devices) • Directive 2014/68/EU (pressure equipment) • Standard EN 13060 (small steam sterilizers) Electromagnetic compatibility: EN 61326 / EN 61000 • Electrical safety: EN 61010-1 / UL 61010-1 • Autoclave safety: EN 61010-2-040 • RoHS Directive 2011/65/EU (products without hazardous substances) By choosing this autoclave, you are opting for reliable, safe equipment that complies with European legislation. In summary: Why choose the ClaveMed F? Fast: The fastest sterilizer in the ClaveMed range Technological: Touch screen, USB port, memory for 9999 cycles Safe: Multiple integrated safety systems Compliant: CE, RoHS, EN13060 standards... Efficient: Cycles adapted to all professional needs Economical: Less waiting = more profitability Ecological: Integrated cleaning cycle to extend the device's lifespan
